MIL-PRF-19500/369H
* TABLE I. Group A inspection - Continued.
Unit
Inspection 1/
MIL-STD-750
Symbol
Limits
Method
Conditions
Min
Max
Subgroup 3
TA = +150°C
High temperature
operation:
mA dc
Collector to emitter
3041
Bias condition A, VBE = -1.5 V dc,
ICEX
5
cutoff current
VCE = 140 V dc
TA = -65°C
Low temperature
operation
Forward current
3076
VCE = 4 V dc, IC = 0.5 A dc,
hFE4
15
transfer ratio
pulsed (see 4.5.1)
Subgroup 4
3251
Test condition A, except test
Pulse response
circuit and pulse requirements in
transfer ratio
accordance with figure 5 herein.
µs
Turn-on time
VCC = 30 V dc, (see figure 5);
ton
8
IC = 0.5 A dc, IB = 50 mA dc
µs
Turn-off time
VCC = 30 V dc, (see figure 5);
toff
15
IC = 0.5 A dc,
IB1 = -IB2 = 50 mA dc
Magnitude of common
3306
VCE = 4 V dc,
|hfe|
4
40
emitter small-signal
IC = 0.5 A dc, f = 100 kHz
short-circuit
forward current
transfer ratio
pF
Open circuit
3236
VCB = 10 V dc,
Cobo
300
IE = 0, 100 kHz ≤ f ≤ 1 MHz
(output
capacitance)
Small-signal short-
3206
VCE = 4 V dc, IC = 0.5 A dc,
hfe
15
100
*
circuit forward-
f = 1.0 kHz.
current transfer
ratio
See footnote at end of table.
9
