MIL-PRF-19500/371H
1.4 Primary electrical characteristics. Unless otherwise specified, TA = +25°C.
hFE1 (1)
hFE2 (1)
VCE(SAT)1
VBE(SAT)1
Cobo
|hfe|
Switching
VCE = 5 V dc
VCE = 10 V dc
VCE = 5 V dc
IC = 1.0 A dc
IC = 1.0 A dc
VCB = 10 V dc
IC = 0.5 A dc
IC = 0.2 A dc
IC = 1.0 A dc
IB = 0.1 A dc
IB = 0.1 A dc
IE = 0
ton
toff
100 kHz ≤ f ≤ 1
f = 1 MHz
MHz
µs
µs
V dc
V dc
pF
Min
25
30
2.5
Max
90
0.8
1.5
250
25
0.8
1.7
(1) Pulsed (see 4.5.1).
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://quicksearch.dla.mil/ or https://assist.dla.mil/ or from the
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
* 2.3 Order of precedence. In the event of a conflict between the text of this document and the references cited
herein, the text of this document takes precedence. Nothing in this document, however, supersedes applicable laws
and regulations unless a specific exemption has been obtained.
