PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, RECTIFIER, MODULE
HIGH VOLTAGE, 1N5597, 1N5600, 1N5603,
JAN, JANTX AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, high voltage, rectifier modules. Three levels of product
assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1.
1.3 Maximum ratings.
Types
VBR(CEO)
VRWM
IO
IFSM
trr
IR(surge)
TJ and TSTG
IF
TC = 75°C
TC = 75°C
TC = 75°C
µs
°C
kV dc
kV (pk)
A dc
A dc
J
A dc
1N5597
10
10
1.0 1/
30
2
1.0
2
-55 to +150
1N5600
5
5
80
6
2.0
2.0 2/
2
-55 to +150
1N5603
5
5
200
12
5.0
5.0 3/
2
-55 to +150
1/ Derate linearly by 13.3 mA dc/°C from IO = 1.0 A dc at TC = +75°C. Derate to zero at TC = +150°C.
2/ Derate linearly by 26.7 mA dc/°C from IO = 2.0 A dc at TC = +75°C. Derate to zero at TC = +150°C.
3/ Derate linearly by 66.7 mA dc/°C from IO = 5.0 A dc at TC = +75°C. Derate to zero at TC = +150°C.
