MIL-PRF-19500/407E
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 3
TA = +150°C
High temperature
operation:
Collector to emitter
3041
10
mA dc
Bias condition A, VCE = 100 V dc,
ICEX2
cutoff current
VBE = -1.5 V dc
TA = -55°C
Low temperature
*
operation:
Forward-current
3076
15
VCE = 4 V dc, IC = 4 A dc,
hFE4
transfer ratio
pulsed (see 4.5.1)
Subgroup 4
⏐hfe⏐
3306
Magnitude of common
8
40
VCE = 4 V dc, IC = 1 A dc,
emitter small-signal
f = 100 kHz
short-circuit forward-
current transfer ratio
Open circuit output
3236
700
pF
VCB = 10 V dc, IC = 0,
Cobo
100 kHz ≤ f ≤ 1 MHz
capacitance
Subgroup 5
Pulse response
3251
Test condition A
µs
Turn-on time
6
VCC = 30 V dc, IC = 4 A dc,
ton
IB1 = 0.4 A dc, see figure 4
µs
Turn-off time
12
VCC = 30 V dc, IC = 4 A dc
toff
IB1 = -IB2 = 0.4 A dc, see figure 4
Subgroup 6
TC = +25°C, 1 cycle, t = 1 s,
Safe operating area
3051
(continuous dc)
(see figure 5)
Test 1
VCE = 7.8 V dc, IC = 15 A dc
Test 2
VCE = 70 V dc, IC = 1.67 A dc
Electrical measurements
See table I, subgroup 2
See footnote at end of table.
7
