MIL-PRF-19500/413F
shall be completed by 15 January 2009.
15 October 2008
SUPERSEDING
MIL-PRF-19500/413E
27 June 2007
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, HIGH-POWER,
TYPES 2N3771 AND 2N3772, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN silicon, high-power transistors for use
in high-speed power-switching applications. Three levels of product assurance are provided for each device type as
specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-3).
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT
VCEO
VEBO
IB
IC
TSTG and TJ
Type
TA =
TC =
VCBO
RθJC
RθJA
+25°C (1) +25°C (2)
°C/W
°C/W
°C
V dc
W
V dc
V dc
V dc
A dc
W
6
150
50
40
7
7.5
30
2N3771
1.17
29.2
-65 to +200
6
150
100
60
7
5.0
20
2N3772
1.17
29.2
-65 to +200
(1) Derate linearly 34.2 mW/°C for TA > +25°C.
(2) Derate linearly 857 mW/°C for TC > +25°C.
1.4 Primary electrical characteristics.
Type
hFE2 at VCE = 4 V dc
VCE(SAT)1 (1)
IC = 15 A dc
IC = 10 A dc
IC = 15 A dc
IC = 10 A dc
IB = 1.5 A dc
IB = 1.0 A dc
Max
Min
Max
V dc
Min
V dc
2N3771
15
60
1.5 Max
2N3772
15
60
1.2 Max
(1) Pulsed (see 4.5.1).
