MIL-PRF-19500/413F
* TABLE I. Group A inspection - Continued.
Unit
Symbol
Inspection 1/
MIL-STD-750
Limits
Min
Max
Method
Conditions
Subgroup 5 - Continued
RBB1 = 2Ω, VBB1 ≤ 10 V dc,
Test 2
RBB2 = 100Ω, VBB2 = 1.5 V dc,
(2N3772 only)
IC = 20 A dc, VCC = 40 ±5 V dc,
RL ≤ 2Ω, L = 5 mH,
0.01Ω (Signal Transformer
Co. CH-30 or equivalent),
CR = 1N1186A, clamp
voltage = 90 +0, -5 V dc,
(device fails if clamp
voltage not reached)
Electrical measurements
See table I, subgroup 2
Subgroup 6
Safe operating area
3053
Load condition C
(unclamped inductive)
(unclamped inductive load)
see figure 5 herein;
TC = +25°C; duty cycle < 10%;
RS = 0.1Ω; RBB2 = 100Ω;
VCC < 15 V dc.
VBB2 = 1.5 V dc;
Test 1 (2N3771 only)
RBB1 = 1Ω, VBB1 < 12 V dc,
IC = 30 A dc, L = 1 mH,
0.005Ω (Signal Transformer
Co. CH-100 or equivalent),
tp ≈ 5 ms.
Test 2 (2N3772 only)
VBB2 = 1.5 V dc,
RBB1 = 2Ω, VBB1 < 12 V dc,
IC = 20 A dc, L = 2 mH,
0.01Ω (Signal Transformer
Co. CH-50 or equivalent),
tp ≈ 5 ms.
Test 3 (both types)
VBB2 = 0 V,
RBB1 < 30Ω, VBB1 < 10 V dc,
IC = 5.5 A dc, L = 40 mH,
0.3Ω (Signal Transformer
Co. CH-8 or equivalent),
tp ≈ 20 ms.
