MIL-PRF-19500/423G

* 4.3 Screening (JANTX, and JANTXV levels only). Screening shall be in accordance with table E-IV of

MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I

herein. Devices that exceed the limits of table I herein shall not be acceptable.

Measurement

Screen (see table IV of

MIL-PRF-19500)

JANTX and JANTXV level

(1) 3c

Thermal impedance (see 4.3.2)

Not applicable

48 hours minimum

ICBO2; hFE4

Subgroups 2 of table I herein; ĆICBO2 = 100 percent of initial value or

5 nA dc, whichever is greater. ĆhFE4 = �15 percent

(1) Shall be performed anytime after temperature cycling, screen 3a; and does not need to be repeated in

screening requirements.

4.3.1 Power burn-in conditions. Power burn-in conditions are as follows: VCB = 10 - 30 V dc. Power shall be

applied to achieve TJ = +135�C minimum using a minimum PD = 75 percent of PT maximum rated as defined in 1.3.

With approval of the qualifying activity and preparing activity, alternate burn-in criteria (hours, bias conditions, TJ, and

mounting conditions) may be used for JANTX and JANTXV quality levels. A justification demonstrating equivalence

is required. In addition, the manufacturing site's burn-in data and performance history will be essential criteria for

burn-in modification approval.

4.3.2 Thermal impedance. The thermal impedance measurements shall be performed in accordance with

method 3131 of MIL-STD-750 using the guidelines in that method for determining IM, IH, tH, tSW (VC and VH where

appropriate). Measurement delay time (tMD) = 70 �s max. See table II, group E, subgroup 4 herein.

4.4 Conformance inspection. Conformance inspection shall be in accordance with MIL-PRF-19500 and as

specified herein. If alternate screening is being performed in accordance with MIL-PRF-19500, a sample of screened

devices shall be submitted to and pass the requirements of subgroup 1 and 2, of table I herein, inspection only (table

E-VIb, group B, subgroup 1 is not required to be performed since solderability and resistance to solvents testing is

performed in table I herein.

4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with MIL-PRF-19500, and table I

herein.
