MIL-PRF-19500/501E
* TABLE I. Group A inspection - Continued.
Inspection 1/
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 5
TC = +25°C +10°C, -0°C, t ≥ 1s, 1
Safe operating area
3051
(dc)
cycle, see figure 4
Test 1
VCE = 12.5 V dc, IC = 12 A dc
Test 2
VCE = 30 V dc, IC = 5 A dc
Test 3
2N6051
VCE = 70 V dc, IC = 200 mA dc
2N6052
VCE = 90 V dc, IC = 155 mA dc
Safe operating area
3053
Load condition B, (clamped inductive
load), TA = +25°C, tr + tf ≤ 1.0 µs duty
(switching)
cycle ≤ 2 percent, tp = 1 ms, (vary to
obtain IC), Rs = 0.1 ohms, RBB1 = 80
ohms, VBB1 = 16 V dc, RBB2 = 100
ohms, VBB2 = 1.5 V dc, VCC = 20 V dc,
IC = 12 A dc, RL ≤ 2 ohms,
L = 10 mH (Stancor C-2688 or
equivalent);
2N6051
clamp voltage = 80 +0, -5 V dc,
2N6052
clamp voltage = 100 +0, -5 V dc.
Device fails if clamp voltage not
reached, see figure 5
Electrical measurements
See table I, subgroup 2
Subgroups 6 & 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
2/ This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroups 2 and 6.
Group E, subgroup 1.
10
