MIL�PRF�19500/502G

TABLE II. Group E inspection (all quality levels) � for qualification and requalification only.

Inspection

Sample plan

Method

Conditions

45 devices

Subgroup 1

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

End-point electrical

See table I, subgroup 2 and 4.6 herein.

measurements

Subgroup 2

45 devices

c=0

VCB ≥ 10 V dc, 6,000 cycles.

Intermittent operation life

1037

End-point electrical

See table I, subgroup 2 and 4.6 herein.

measurements

Subgroup 4

Sample size N/A

Thermal impedance curves

Subgroup 8

45 devices

c=0

Reverse voltage leakage

1033

Condition B.

stability
