MILPRF19500/502G
Dimensions
Symbol
Notes
Inches
Millimeters
Min
Max
Min
Max
CD
.875
22.23
CH
.250
.328
6.35
8.33
HR
.495
.525
12.57
13.34
HR1
.131
.188
3.33
4.78
3
HT
.060
.135
1.52
3.43
LD
.038
.043
0.97
1.09
4,5
LL
.312
.500
7.92
12.7
4
L1
.050
1.27
4,5
MHD
.151
.161
3.84
4.09
6
MHS
1.177
1.197
29.90
30.40
PS
.420
.440
10.67
11.18
7, 8
.205
.225
5.21
5.72
7, 4, 8
PS1
.655
.675
16.64
17.15
7
S1
NOTES:
1. Dimensions are in inches. Millimeters are given for general information only.
2. Body contour is optional within zone defined by dimension CD.
3. At both ends.
4. Both terminals.
5. Dimension LD applies between dimension L1 and LL. Lead diameter shall not exceed twice dimension LD
within dimension L1. Diameter is uncontrolled in dimension L1.
6. Two holes.
7. These dimensions shall be measured at points .050 inch (1.27 mm) to .055 inch (1.40 mm) below the
seating plane. When gauge is not used, measurement shall be made at seating plane.
8. The seating plane of the header shall be flat within .001 inch (0.03 mm) concave to .004 inch (0.10 mm)
convex inside a .930 inch (23.62 mm) diameter circle on the center of the header and flat within .001 inch
(0.03 mm) concave to .006 inch (0.15 mm) convex overall.
9. The collector shall be electrically connected to the case.
10. In accordance with ASME Y14.5M, diameters are equivalent to φ symbology.
* FIGURE 1. Physical dimensions and schematic circuit (TO204AA, similar to TO3) Continued.
