MIL-PRF-19500/510J

TABLE III. Group E inspection (all quality levels) for qualification or re-qualification only.

Qualification and

MIL-STD-750

Inspection

large lot quality

Method

Conditions

conformance

inspection

Subgroup 1

45 devices

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

End-point electrical

See table I, subgroup 2 .

measurements

Subgroup 2

45 devices

c=0

Intermittent life

1037

VCB = 10 V dc, 6,000 cycles, adjust power or current

to achieve ĆTJ = +100�C.

End-point electrical

See table I, subgroup 2 .

measurements

Subgroup 4

Sample size

N/A

Thermal impedance

See MIL-PRF-19500.

curves

Subgroup 5

15 devices

c=0

Barometric pressure

1001

Condition C, see 1.3, all devices.

Subgroup 8

45 devices

c=0

Condition A for devices ≥ 400 V, condition B for

Reverse stability

1033

devices < 400 V.
