The documentation and process conversion
INCH POUND
measures necessary to comply with this document
MIL-PRF-19500/510J
shall be completed by 13 February 2014.
13 December 2013
SUPERSEDING
MIL-PRF-19500/510H
14 January 2013
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER,
TYPE 2N6249, 2N6249T1, 2N6249T3, 2N6250, 2N6250T1, 2N6250T3, 2N6251, 2N6251T1, 2N6251T3,
JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHCB,
JANKCB, JANKCBM, JANKCBD, JANKCBP, JANKCBL, JANKCBR, JANKCBF, JANKCBG, AND JANKCBH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN silicon, power transistors. Four
levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product
assurance are provided for each unencapsulated device type. Provisions for radiation hardness assurance (RHA) to
eight radiation levels is provided for JANS and JANKC product assurance levels. RHA level designators "M", "D", "P",
"L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA
requirements.
1.2 Physical dimensions. See figure 1 (similar to TO-3), figure 2 (JANHC and JANKC), figure 3 (TO-254AA), and
figure 4 (TO-257AA).
1.3 Maximum ratings at TA = +25°C, unless otherwise specified.
TJ and
VCBO
PT (1)
VCEO
VEBO
IC
IB
PT
RθJC
Type
(2)
TSTG
TC = +25°C
TA = +25°C
W
W
V dc
V dc
V dc
A dc
A dc
°C/W
°C
2N6249
6.0
175
1.0
300
200
6.0
10
5.0
2N6249T1
6.0
175
1.0
300
200
6.0
10
5.0
-65
2N6249T3
4.0
(3) 125
1.3
300
200
6.0
10
5.0
2N6250
6.0
175
1.0
375
275
6.0
10
5.0
to
2N6250T1
6.0
175
1.0
375
275
6.0
10
5.0
2N6250T3
4.0
(3) 125
1.3
375
275
6.0
10
5.0
+200
2N6251
6.0
175
1.0
450
350
6.0
10
5.0
2N6251T1
6.0
175
1.0
450
350
6.0
10
5.0
2N6251T3
4.0
(3) 125
1.3
450
350
6.0
10
5.0
(3) For TO-257 devices with typical mounting and small footprint, conservatively rating at 125 W and 1.3°C/W only.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.dla.mil.
AMSC N/A
FSC 5961
