MIL-PRF-19500-514 Semiconductor Device, Transistor, Npn, Silicon, Power, Types 2N6274 And 2N6277, Jan, Jantx, And JantxvThis specification covers the performance requirements for NPN silicon, power transistors. Three levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . . . . . .
MIL-PRF-19500/514D
TABLE II. Groups B and C delta measurements. 1/ 2/ 3/
Steps
Inspection
Symbol
Limits
Unit
Method
Conditions
Min
Max
± 50 mV change
ĆVCE(sat)1
1.
Collector to
3071
IC = 20 A dc; IB = 2 A dc,
emitter voltage
from previously
pulsed (see 4.5.1)
(saturated)
measured
value.
1/
The delta measurements for table E-VIB (JANTX and JANTXV) of MIL-PRF-19500 are subgroup 6, see table
II herein, step 1.
2/
The delta measurements for table E-VII of MIL-PRF-19500 are subgroup 6, see table II herein, step 1.
3/
The delta measurements for table E-XI of MIL-PRF-19500 are subgroups 1 and 2, see table II herein, step 1.
10
