MIL-PRF-19500/518D
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Limits
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 4
Pulse response:
3251
Test condition A, except test
circuit and pulse requirements in
accordance with figure 2 herein.
μs
Turn-on time
VCC = 30 V dc, IC = 0.5 A dc,
ton
0.25
IB1 = 0.05 A dc
μs
Turn-off time
VCC = 30 V dc, IC = 0.5 A dc,
toff
2.5
IB1 = IB2 = .05 A dc
⏐hfe⏐
Magnitude of common
3306
VCE = 10 V dc, IC = 500 mA dc,
1
8
emitter small-signal
f = 10 MHz
short-circuit
forward-current
transfer ratio
3236
VCB = 10 V dc, IE = 0,
Open capacitance
Cobo
50
pF
*
(open circuit)
0.1 MHz ≤ f ≤ 1.0 MHz
Subgroup 5
TC = +25°C, power application
Safe operating area
3051
(continuous dc)
t = 1 s, 1 cycle, (see figure 3)
VCE = 6.25 V dc, IC = 4 A dc
Test 1
Test 2
VCE = 20 V dc, IC = 1.25 A dc
Test 3
2N3766
VCE = 50 V dc, IC = 150 mA dc
2N3767
VCE = 65 V dc, IC = 150 mA dc
See footnotes at end of table.
