MIL-PRF-19500/527E
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 5 - Continued
Safe operating area
Load condition B (clamped inductive load)
(switching)
(see figure 5); TA = +25°C; tr + tf ≤ 1.0 µs;
duty cycle ≤ 10 percent; tp = 5 ms; (vary to
obtain IC); Rs = 0.1 ohms; VCC = -10 V dc;
IC = -10 A dc
2N6648
Clamp voltage = -40 V dc
2N6649
Clamp voltage = -60 V dc
2N6650
Clamp voltage = -80 V dc
Device fails if clamp voltage not reached.
Electrical measurements
See table I, subgroup 2
Subgroups 6 and 7
Not applicable
1/ For sampling plan see MIL-PRF-19500.
*
2/ This test required for the following end-point measurements only:
Group B, subgroups 2 and 3.
Group C, subgroups 2 and 6.
Group E, subgroup 1.
11
