MIL-PRF-19500/527E

* TABLE II. Group E inspection (all quality levels) - for qualification or re-qualification only.

MIL-STD-750

Qualification

Inspection

Method

Conditions

Subgroup 1

45 devices

c=0

1051

Test condition C, 500 cycles

Temperature cycling

1071

Hermetic seal

Fine leak

Gross leak

See table I, subgroup 2 herein.

Electrical measurements

45 devices

Subgroup 2

c=0

TA = +150�C, VCB = 80 percent of rated voltage,

1048

DC blocking life

1,000 hours.

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 4

Thermal impedance curves

See MIL-PRF-19500.

Sample size

N/A

Subgroup 5

Not applicable

Subgroup 6

3 devices

Electrostatic discharge (ESD)

1020

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
