MIL-PRF-19500/528B
* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Limit
Unit
Symbol
Method
Conditions
Min
Max
Subgroup 4 - Continued
Pulse response:
3251
Test condition A except test circuit
and pulse requirements in
accordance with figure 3.
s
Turn-on time
ton
0.5
VCC = 30 V dc 2; IC = 50 A dc;
2N6032
IB1 = 5.0 A dc
VCC = 30 V dc 2; IC = 40 A dc;
2N6033
IB1 = 4.0 A dc
s
Turn-off time
toff
2.0
VCC = 30 V dc 2; IC = 50 A dc;
2N6032
IB2 = 5.0 A dc, IB2 = -5.0 A dc
VCC = 30 V dc 2; IC = 40 A dc;
2N6033
IB1 = 4.0 A dc, IB2 = -4.0 A dc
Subgroup 5
TC = +25C; t = 1 s; 1 cycle;
Safe operating area
3051
(continuous dc)
(see figure 4)
Test 1
IC = 50 A dc; VCE = 2.8 V dc
2N6032 only
Test 2
IC = 40 A dc; VCE = 3.5 V dc
2N6033 only
Test 3
IC = 5.8 A dc; VCE = 24 V dc
Test 4
IC = 0.9 A dc; VCE = 40 V dc
Test 5
IC = 0.18 A dc; VCE = 90 V dc
2N6032 only
Test 6
IC = 0.1 A dc; VCE = 120 V dc
2N6033 only
See footnote at end of table.
9
