MIL-PRF-19500-544 Semiconductor Device, Transistor, Npn, Silicon, Power, Types 2N5152, 2N5154, 2N5152L, 2N5154L, 2N5152U3, 2N5154U3, Jan, Jantx, Jantxv, Jantxvf, Jantxvr, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhcb, Janhcd, Janhce, Jankcb, Jankcbf, Jankcd, Jankce, Jankcdm, Jankcdd, Jankcdp, Jankcdl, Jankcdr, Jankcdf, Jankcdg, And JankcdhThis specification covers the performance requirements for NPN, silicon, power transistors for use in high-speed power-switching applications. Four levels of product assurance are provided for each encapsulated device type and two levels of product assurance are provided for each unencapsulated device type as specified in MIL-PRF-19500. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


. . . . . . . . . . . . . . . . .
MIL-PRF-19500/544H
TABLE III. Group E inspection (all quality levels) - for qualification only.
Inspection
Qualification
Method
Conditions
Subgroup 1
45 devices
c=0
1051
Test condition C, 500 cycles
Temperature cycling (air to
air)
Hermetic seal
Fine leak
1071
Gross leak
See table I, subgroup 2 and table IV herein
Electrical measurements
Subgroup 2
45 devices
c=0
1037
Intermittent life
VCB = 10 V dc, 6,000 cycles
See table I, subgroup 2 and table IV herein
Electrical measurements
Subgroup 4
See MIL-PRF-19500, table E-IX, group E, subgroup 4
Thermal impedance
Subgroup 5
Not applicable
Subgroup 8
45 devices
c=0
Reverse stability
1033
Condition B
TABLE IV. Groups B, C and E delta and electrical measurements. 1/ 2/ 3/ 4/
Step
Inspection
Symbol
Limits
Unit
Method
Conditions
Min
Max
±20 percent
ĆhFE2
1.
Forward - current
3076
IC = 2.5 A dc, VCE = 5 V dc, pulsed
transfer ratio
change from
(see 4.5.1)
initial reading
1/ The delta measurements for table E-VIA (JANS) of MIL-PRF-19500 are as follows: Subgroups 4 and 5, see table
IV herein, step 1.
2/ The delta measurements for 4.4.2.2 (JAN, JANTX and JANTXV) are as follows: All steps, see table IV herein,
step 1.
3/ The delta measurements for table E-VII of MIL-PRF-19500 are as follows: Subgroup 6, see table IV herein,
step 1.
4/ The delta measurements for 4.4.5 are as follows: Subgroups 1 and 2, see table IV herein, step 1.
20
