MIL-PRF-19500/551G

* TABLE III. Group E inspection (all quality levels) for qualification only.

Inspection

Sampling plan

Method

Conditions

45 devices,

Subgroup 1

c=0

500 cycles, condition C, -55�C to +175�C

Temperature cycling

1051

See table I, subgroup 2

Electrical measurements

Subgroup 2

22 devices,

c=0

1,000 hours. See 4.3.1

Life test

1048

See table I, subgroup 2

Electrical measurements

Subgroups 3, 4 and 5

Not applicable

Subgroup 8

See 4.5.2. IPP shall be characterized by the supplier

Peak pulse current

and this data shall be available to the Government.

Test shall be performed on each low and high voltage

device for each structurally identical grouping. Test to

failure.

Electrical measurements

See table I, subgroup 2

Subgroup 9

Resistance to glass

1057

Condition B

cracking.
