INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/564H
shall be completed by 2 September 2009.
2 June 2009
SUPERSEDING
MIL-PRF-19500/564G
13 June 2005
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, FIELD EFFECT TRANSISTOR, P-CHANNEL, SILICON,
TYPES 2N6849, 2N6849U, 2N6851 AND 2N6851U,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a P-channel, enhancement-mode,
MOSFET, power transistor. Four levels of product assurance are provided for each encapsulated device type as
specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.
* 1.2 Physical dimensions. See figure 1, TO-205AF (formerly TO-39), 2 (LCC), and figures 3 and 4 for JANHC and
JANKC die dimensions.
* 1.3 Maximum ratings. Unless otherwise specified, TC = +25C.
VDG
VGS
ID1 (3) (4) ID2 (3) (4)
IDM
TJ and TSTG
Type
PT (1)
IS
PT
VDS
RJC
TC =
TC =
TC =
TA =
(2)
+25C
+100C
+25C +25C
(5)
C
C/W V dc
W
V dc
V dc
W
A dc
A dc
A dc
A (pk)
20
2N6849, 2N6849U
25
0.8
5.0
-100
-100
-6.5
-4.1
-6.5
-25
-55 to +150
20
2N6851, 2N6851U
25
0.8
5.0
-200
-200
-4.0
-2.4
-4.0
-20
-55 to +150
Derate linearly by 0.2 W/C for TC > +25C.
(1)
(2)
See figure 5, thermal impedance curves.
(3)
The following formula derives the maximum theoretical ID spec. ID is limited by package and device
construction.
TJM - TC
ID =
RJC x R DS ( on ) at TJM
(4)
See figure 6, maximum drain current graphs.
IDM = 4 x ID1 as calculated in note 2.
(5)
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
