MIL-PRF-19500/589A

TABLE II. Group E inspections (all quality levels) for qualification only.

Inspections

MIL-STD-750

Quality conformance

inspection sample size

Method

Conditions

45 devices, c = 1

Subgroup 1

Thermal shock

1051

-55 C to +150 C

(temperature shock)

500 cycles

1071

Hermetic seal

Fine leak

Gross leak

Electrical measurements

See table V, steps 1, 2, 3, 4, 5, 6, and

Subgroup 2 2/

45 devices, c = 1

Steady-state reverse bias

1042

Condition A, 1,000 hours

TJ = 150 C +0 C, -15 C

Electrical measurements

See table V, steps 1, 2, 3, 4, 5, 6, and

Steady-state gate bias

1042

Condition B, 1,000 hours

TA = +150 C

Electrical measurements

See table V, steps 1, 2, 3, 4, 5, 6, and

Subgroup 3

DPA

2102

5 devices, c = 0

Subgroup 4

Thermal resistance

3103

See 4.5.2

3101

5 devices, c = 0

Subgroup 5

Barometer pressure test

1001

Condition C,

VCE = 600 V maximum,

I(ISO) = 0.25 mA

1/ In initial design verification only (1 time testing).

2/ A separate sample shall be pulled for each test.
