MIL-PRF-19500/609K
4.2 Qualification inspection. Qualification inspection shall be in accordance with MIL-PRF-19500 and as specified
herein.
4.2.1 JANHC and JANKC qualification. JANHC and JANKC qualification inspection shall be in accordance with
MIL-PRF-19500.
4.2.2 Group E qualification. Group E inspection shall be performed for qualification or re-qualification only. In
case qualification was awarded to a prior revision of the specification sheet that did not require the performance of
table II tests, the tests specified in table II herein that were not performed in the prior revision shall be performed on
the first inspection lot of this revision to maintain qualification.
4.3 Screening (JANS, JANTXV, and JANTX levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500, and as specified herein. Specified electrical measurements shall be made in accordance with table
Screen
(see table E-IV of
JANS level
JANTXV and JANTX level
MIL-PRF-19500)
2
Not required
Not required
3b
Not applicable
Not applicable
(1) 3c
Thermal impedance (see 4.3.3)
Thermal impedance (see 4.3.3)
4
Not applicable
Not applicable
5
Not applicable for axial leaded devices
Not applicable
6
Not applicable
Not applicable
IR1
9
Not applicable
10
Method 1038 of MIL-STD-750, condition A
Method 1038 of MIL-STD-750, condition A
VF4 (1N6640, 1N6641) or
VF5 (1N6639), IR1; and V(BR) ; ĆIR1 ±15 nA dc
11
VF4 (1N6640, 1N6641) or
or 100 percent of initial value whichever is
VF5 (1N6639) and IR1
greater
12
Required, see 4.3.2
Required, see 4.3.2
Subgroups 2 and 3 of table I herein;
Subgroup 2 of table I herein;
ĆIR1 ≤ 100 percent of initial reading or
ĆIR1 ≤100 percent of initial reading or
13
15 nA dc, whichever is greater;
15 nA dc, whichever is greater;
ĆVF4 ≤ ±0.030 V dc for 1N6640, 1N6641),
ĆVF4 ≤ ±0.030 V dc for 1N6640, 1N6641),
ĆVF5 ≤ ±0.030 V dc for 1N6639,
ĆVF5 ≤ ±0.030 V dc for 1N6639,
(scope display, see 4.5.3)
(scope display, see 4.5.3)
(1) Thermal impedance shall be performed any time after screen 3; JANTX and JANTXV levels do not need to be
repeated in screening requirements.
4.3.1 Screening (JANHC and JANKC). Screening of JANHC and JANKC die shall be in accordance with appendix
G of MIL-PRF-19500. Burn-in duration for the JANKC level follows JANS requirements; the JANHC follows JANTX
requirements.
8
