MIL-PRF-19500/617D
TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 5
Not applicable
Subgroup 6
Surge
4066
Mounting conditions in
accordance with test method 1026
of MIL-STD-750,
TA = +25C, IFSM = (see 1.3),
IO = 0; VRM(w) = 0; six surges; TA
= 25°C, tp = 8.3 ms, one minute
minimum time between surges.
Electrical
See table I, subgroup 2 herein,
measurements
with the exception of ZJX.
Subgroup 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
2/ The reverse breakdown characteristics shall be viewed on an oscilloscope with display calibration factors of 50 to
100 A/division and 50 to 100 V/division. Reverse current over the knee shall be at least 500 A. Each device
may exhibit a slightly rounded characteristic and any discontinuity or dynamic instability of the trace shall be cause
for rejection.
