MIL-PRF-19500/617D

* TABLE II. Group E inspection (all quality levels) for qualification and requalification only.

Inspection

MIL-STD-750

Sampling

plan

Method

Conditions

22 devices

Subgroup 1

c=0

500 cycles, -65C to +175C.

Temperature cycling

1051

Hermetic seal

1071

Electrical measurements

See table I, subgroup 2 and table III, steps 1 and 2. For

irradiated devices, include trr as an end-point

measurement.

Subgroup 2

22 devices

c=0

Steady-state dc blocking

1048

t = 1,000 hours VR = 80 percent Vrated

life

Electrical measurements

See table I, subgroup 2 and table III, steps 1 and 2. For

irradiated devices, include trr as an end-point

measurement.

Subgroup 4

Sample size

N/A

See MIL-PRF-19500.

Thermal impedance

curves

Subgroup 5

22 devices

c=0

VR = rated VR (see 1.3); pressure = 33 mm Hg; t = 1 minute

Barometric pressure,

1001

(minimum), RISO = 2.0 x 106 ohm max. IR = IR1

reduced (altitude

operation).

Subgroup 6

Not applicable

Subgroup 8

22 devices

Forward surge

4066

c=0

Electrical measurements

See table I, subgroup 2 herein.
