INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/158T
shall be completed by 4 May 2009.
4 February 2009
SUPERSEDING
MIL-PRF-19500/158R
2 April 2008
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, DIODE, SILICON, TEMPERATURE COMPENSATED,
VOLTAGE-REFERENCE, TYPES 1N3154-1, THROUGH 1N3157-1, AND 1N3154UR-1
THROUGH 1N3157UR-1, JAN, JANTX, JANTXV, AND JANS, RADIATION HARDENED
(TOTAL DOSE ONLY) JANTXVM, D, L, R, F, G, H, AND JANSM, D, L, R, F, G, H
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for 8.4 volts 5 percent, silicon, temperature
compensated, voltage-reference diodes. Four levels of product assurance are provided for each encapsulated device
type as specified in MIL-PRF-19500. Seven levels of radiation hardened (total dose only) product assurance are
provided for each encapsulated device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (similar to DO-7 and DO-35) and figure 2 (DO-213AA).
1.3 Maximum ratings. Unless otherwise specified TA = +25C.
Power derating above TA = +25C
PT
TSTG and TJ
IZM (1)
C
mW/C
mW
mA dc
500
-55 to +175
55
3.33
(1) To guarantee voltage temperature stability, it is necessary to maintain the proper IZ = 10 mA.
1.4 Primary electrical characteristics. Unless otherwise specified, primary electrical characteristics at TA = +25C.
VZ
VZ (1)
ZZ
IR
Type
(voltage-temperature
(1)
Min
Max
stability) (1)
VR = 5.5 V
A
mV dc
ohms
volts
volts
1N3154-1, 1N3154UR-1
130.0
15
7.98
8.82
10.0
1N3155-1, 1N3155UR-1
65.0
15
7.98
8.82
10.0
1N3156-1, 1N3156UR-1
26.0
15
7.98
8.82
10.0
1N3157-1, 1N3157UR-1
13.0
15
7.98
8.82
10.0
(1) To guarantee voltage temperature stability, it is necessary to maintain the proper IZ = 10 mA.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil .
FSC 5961
AMSC N/A
