INCH-POUND
* The documentation and process conversion measures
MIL-PRF-19500/312E
necessary to comply with this document shall be
30 March 2006
completed by 30 June 2006.
SUPERSEDING
MIL-PRF-19500/312D
20 February 2001
* PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, SWITCHING,
TYPE 2N708, JAN, JANTX, AND JANHC
Inactive for new design after 7 June 1999.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the detail requirements for NPN silicon switching transistors. Two levels of
product assurance are provided for the device type as specified in MIL-PRF-19500. One level of product assurance is
provided for die.
1.2 Physical dimensions. See figure 1 (TO-18) and figure 2 (die).
1.3 Maximum ratings unless otherwise specified TA = +25°C.
*
VCEO
VEBO
PT (1)
VCBO
TJ and TSTG
RθJA
VCER
TA = +25°C
RBE ≤ 10 ohms
°C/W
°C
W
V dc
V dc
V dc
V dc
0.5
40
15
5.0
20
325
-65 to +200
(1) Derate linearly 3.08 mW/°C above TA = +37.5°C.
