MIL-PRF-19500/312E

* TABLE III. Group E inspection (all quality levels) - for qualification or re-qualification only.

Qualification

MIL-STD-750

Inspection

Method

Conditions

Subgroup 1

45 devices

c=0

Temperature cycling

1051

Test condition C, 500 cycles

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2 and table II herein.

Subgroup 2

45 devices

c=0

Intermittent life

1037

Intermittent operation life: VCB = 10 V dc, 6,000 cycles. Adjust

device current, or power, to achieve a minimum ĆTJ of +100�C.

Electrical measurements

See table I, subgroup 2 and table II herein.

Subgroup 4

See MIL-PRF-19500.

Sample size

Thermal impedance

N/A

curves

Subgroup 5

Not applicable

Subgroup 6

3 devices

Electrocstatic discharge

1020

(ESD)

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B for devices < 400 V.
