MIL-PRF-19500/312E
TABLE II. Groups A, B, and C delta measurements. 1/
Step
Inspection
Symbol
Unit
MIL-STD-750
Limits
Method
Conditions
Min
Max
ĆhFE2
±25 percent change
1.
Forward-current
3076
VCE = 1.0 V dc;
from initial value
transfer ratio
IC = 10 mA dc;
pulsed (see 4.5.1)
1/ The delta measurements for 4.4.2.1 herein (group B, JAN and JANTX) are as follows: All steps of table II shall be
performed after each step in 4.4.2.1 herein.
