MIL-PRF-19500/343K
* TABLE I. Group A inspection - Continued.
MIL-STD-750
Limits
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 4 - Continued.
Collector-base time
4
15
ps
VCB = 6 V dc; IE = 2 mA dc;
rb' Cc
constant
f = 31.9 MHz (see figure 8)
Subgroups 5, 6, and 7
Not applicable
1/ For sampling plan (unless otherwise specified), see MIL-PRF-19500.
2/ For resubmission of failed subgroup A1, double the sample size of the failed test or sequence of tests. A failure
in group A, subgroup 1 shall not require retest of the entire subgroup. Only the failed test shall be rerun upon
submission.
3/ Separate samples may be used.
4/ Not required for JANS devices.
5/ Not required for laser marked devices.
6/ This hermetic seal test is an end-point to temp-cycling in addition to electrical measurements.
