MIL-PRF-19500/343K

TABLE III. Groups B, C, and E delta measurements. 1/ 2/ 3/ 4/

MIL-STD-750

Step

Inspection

Limit

Symbol

Unit

Method

Conditions

Min

Max

100 percent of initial value

ĆICB01

Collector-base cutoff

3036

Bias condition D;

or 5 nA dc, whichever is

current

VCB = 15 V dc

greater.

ĆhFE1

�25 percent change from

Forward current

3076

VCE = 1.0 V dc;

transfer ratio

IC = 3 mA dc

initial value.

ĆVCE(sat)

�50 mV dc change from

Collector to emitter

3071

IC = 10 mA dc;

voltage (saturated)

IB = 1.0 mA dc

initial value.

1/ The delta measurements for table E-VIa (JANS) of MIL-PRF-19500 are as follows:

a. Subgroup 3, see table II herein, step 1.

b. Subgroups 4 and 5, see table II herein, step 3.

2/ The delta measurements for group B, 4.4.2.2 herein (JAN, JANTX, and JANTXV) are as follows:

Steps 1, 2, and 3 of 4.4.2.2, see table II herein, all steps.

3/ The delta measurements for table E-VII (JANS) of MIL-PRF-19500 are as follows:

a. Subgroup 2 and 3, see table II herein, step 1.

b. Subgroup 6, see table II herein, all steps.

4/ The delta measurements for table E-IX of MIL-PRF-19500 are: Subgroups 1 and 2, see table II herein, all steps.

5/ Devices which exceed the group A limits for this test shall not be acceptable.
