The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
MIL-PRF-19500/359K
completed by 2 January 2011.
2 October 2010
SUPERSEDING
MIL-PRF-19500/359J
18 February 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, FAST RECOVERY, POWER RECTIFIER,
1N4942, 1N4944, 1N4946, 1N4947, AND 1N4948,
JAN, JANTX, AND JANTXV
nactive for new design after 27 February 1992 For
new design use - 1N5615, 1N5617, 1N5619,
1N5621, 1N5623 on MIL-PRF-19500/429.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a silicon, fast recovery semiconductor
power rectifier diode for use in equipment circuits. Three levels of product assurance are provided for each device as
specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 axial package.
1.3 Maximum ratings. Unless otherwise specified, TA= +25°C.
RθJL L =
Device
VRWM
IO
IO
IFSM at
trr1 at
.375 inch
type
TA =
TA =
tp = 8.3 ms
IF = 0.5 A,
TSTG and TJ
RθJX
(9.52 mm)
IR = 1.0 A
+55°C
+100°C
IO = .750 A dc
(4)
IREC = 0.25 A
(1) (2) (3)
(2) (3)
TA = +55°C
A dc
A pk
ns
A dc
°C
°C /W
°C/W
V
-65°C to
1N4942
200
1.0
.750
15
38
150
115
+175°C
1N4944
400
1.0
.750
15
38
150
115
1N4946
600
1.0
.750
15
38
250
115
1N4947
800
1.0
.750
15
38
250
115
1N4948
1,000
1.0
.750
15
38
500
115
See notes on next page.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dscc.dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.daps.dla.mil .
AMSC N/A
