MIL-PRF-19500/376K
30 March 2013
SUPERSEDING
MIL-PRF-19500/376J
20 November 2010
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, LOW-POWER,
TYPES 2N2484, 2N2484UA, 2N2484UB, 2N2484UBC, 2N2484UBN, 2N2484UBCN JAN, JANTX, JANTXV,
JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH JANHCA, JANHCB, JANKCA,
JANKCB, JANKCM, JANKCD, JANKCP, JANKCL, JANKCR, JANKCF, JANKCG, AND JANKCH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, low-power transistors. Four
levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product
assurance are provided for die. RHA level designators "M", "D", "P", "L", "R", "F', "G" and "H" are appended to the
device prefix to identify devices, which have passed RHA requirements.
* 1.2 Physical dimensions. See figure 1 (similar to TO-18), figure 2, (surface mount case outlines UA), figure 3,
(surface mount case outlines UB, UBC, UBN, and UBCN), and figures 4 and 5 (die).
1.3 Maximum ratings. Unless otherwise specified TA = +25C.
*
Types
PT (1)
VCBO
VEBO
VCEO
IC
TJ and TSTG
RJA
RJSP
(2)
(2)
TA = +25C
C
C/W
C/W
mW
V dc
V dc
V dc
mA dc
2N2484
360
60
6
60
50
-65 to +200
325
N/A
2N2484UA
360
60
6
60
50
-65 to +200
275
110
2N2484UB, UBN
360
60
6
60
50
-65 to +200
350
100
2N2484UBC, UBCN
360
60
6
60
50
-65 to +200
350
100
(1) For derating see figures 6, 7, and 8.
(2) For thermal impedance see figures 9, 10, 11, 12, and 13.
