MIL-PRF-19500-437 Semiconductor Device, Diode, Silicon, Low-Noise Voltage Regulator, Types 1N5518B-1, 1N5518C-1, 1N5518D-1 Through 1N5546B-1, 1N5546C-1, 1N5546D-1, 1N5518Bur-1, 1N5518Cur-1, 1N5518Dur-1 Through 1N5546Bur-1, 1N5546Cur 1, 1N5546Dur-1, Jan, Jantx, Jantxv, Janhc, And JankcThis specification covers the performance requirements for 500 milliwatt, silicon, low-noise, voltage regulator diodes with voltage tolerances of 5 percent, 2 percent, and 1 percent. Three levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type die. For JANHC and JANKC quality levels \(see 6.5\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/437H

Dimensions

Ltr

Inches

Millimeters

Notes

Min

Max

Min

Max

.055

.090

1.40

2.29

.120

.200

3.05

5.08

.018

.022

0.46

0.56

1.000

1.500

25.40

38.10

.050

1.27

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Package contour optional within BD and length BL. Heat slugs, if any,

shall be included within this cylinder but shall not be subject to minimum

limit of BD. The BL dimension shall include the entire body including

slugs.

4. Within this zone lead, diameter may vary to allow for lead finishes and

irregularities other than heat slugs.

5. In accordance with ASME Y14.5M, diameters are equivalent to Φx

symbology.

FIGURE 1. Physical dimensions types 1N5518B-1, C-1, and D-1

through 1N5546B-1, C-1, D-1 (DO-35).
