INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/441K
shall be completed by 30 June 2010.
30 March 2010
SUPERSEDING
MIL-PRF-19500/441J
14 November 2006
PERFORMANCE SPECIFICATION SHEET
*
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, POWER,
TYPES 2N3740, 2N3740U4, 2N3741, AND 2N3741U4,
JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHCC,
JANKCC, JANKCCM, JANKCCD, JANKCCP, JANKCCL, JANKCCR, JANKCCF, JANKCCG, and JANKCCH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for PNP, silicon, power transistors. Four
levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two
levels of product assurance are provided for each unencapsulated device type. Provisions for radiation hardness
assurance (RHA) to eight radiation levels is provided for JANTXV, JANS, JANHC, and JANKC product assurance
levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify
devices, which have passed RHA requirements.
* 1.2 Physical dimensions. See figure 1, TO-66, figure 2 (U4, surface mount) for encapsulated devices, and figure 3
for unencapsulated devices (JANHC and JANKC).
* 1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
Types
PT (1)
VCBO
VCEO
VEBO
RθJC
RθJC
IB
IC
TSTG and TJ
(2)
(2)
T0-66
U4
TC =
TA =
TC =
only
only
+25°C
+25°C
+100°C
°C/W
°C/W
°C
W
W
W
V dc
V dc
V dc
A dc
A dc
2N3740, 2N3740U4
25
3
14
7
6
60
60
7
2
4
-65 to +200
2N3741, 2N3741U4
25
3
14
7
6
80
80
7
2
4
-65 to +200
(1)
See figures 4 and 5 for temperature-power derating curves.
(2)
See figures 6 and 7, transient thermal impedance graphs.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
