MIL-PRF-19500/441K
TABLE II. Group B, C, and E delta measurements. 1/ 2/ 3/ 4/
Inspection
Step
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
ĆICEX1
1.
Collector to emitter
3041
Bias condition A;
100 percent
cutoff current
of initial value
VBE = 1.5 V dc
or 50 nA dc,
2N3740, 2N3740U4
whichever is
VCE = 60 V dc
greater.
2N3741, 2N3741U4
VCE = 80 V dc
±25 percent
ĆhFE2
2.
Forward-current
3076
VCE = 1 V dc;
transfer ratio
change from
IC = 250 mA dc;
initial reading.
pulsed (see 4.5.1)
ĆVCE(sat)1
3.
Saturation voltage
3071
50 mV dc
IC = 250 mA dc;
and resistance
change from
IB = 25 mA dc;
initial value.
pulsed (see 4.5.1)
1/
The delta measurements for table E-VIA (JANS) of MIL-PRF-19500 are as follows:
a. Subgroup 4, see table II, step 3.
b. Subgroup 5, see table II, steps 1, 2, and 3.
2/
The delta measurements for 4.4.2.2, group B (JAN, JANTX, and JANTXV) of MIL-PRF-19500 are after each
step in 4.4.2.2, see table II, steps 1, 2, and 3.
3/
The delta measurements for table E-VII of MIL-PRF-19500 are as follows: Subgroup 6, see table II, steps 1
and 2 (JANS only).
4/
The delta measurements for table E-IX (all quality levels) of MIL-PRF-19500 are as follows: Subgroup 1,
see table II, step 2; subgroup 2, see table II, steps 1 and 2.
