INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/485N
completed by 10 September 2013.
10 June 2013
SUPERSEDING
MIL-PRF-19500/485M
1 June 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, LOW-POWER
TYPES: 2N5415, 2N5415S, 2N5415UA, 2N5415U4, 2N5416, 2N5416S, 2N5416UA,
AND 2N5416U4, JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL,
JANSR, JANSF, JANSG, JANSH, JANHCB, JANHCD, JANKCB, JANKCD, JANKCBM,
JANKCBD, JANKCBP, JANKCBL, JANKCBR, JANKCBF, JANKCBG, AND JANKCBH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, switching transistors. Four
levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product
assurance are provided for each unencapsulated device type. Provisions for radiation hardness assurance (RHA) to
eight radiation levels is provided for JANTXV, JANS, JANHC, and JANKC product assurance levels. RHA level
designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have
passed RHA requirements.
1.2 Physical dimensions. See figure 1 (similar to TO-5), figures 2 and 3 for JANHC and JANKC (die) dimensions,
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT (1)
Types
PT (2)
IC
PT (3)
VCBO
VCEO
VEBO
TSTG
RθJA
RθJC
RθJSP
TC = +25°C
TA = +25°C
TSP = +25°C
and TJ
°C/W
°C/W
°C/W
°C
W
W
W
V dc
V dc
V dc
A dc
2N5415, S
0.75
10
200
200
6.0
1.0
234
17.5
N/A
2N5415UA
0.75
2
200
200
6.0
1.0
234
80
-65 to
2N5415U4
1
15
200
200
6.0
1.0
145
12
N/A
+200
2N5416, S
0.75
10
350
300
6.0
1.0
234
17.5
N/A
2N5416UA
0.75
2
350
300
6.0
1.0
234
80
2N5416U4
1
15
350
300
6.0
1.0
145
12
N/A
(1) Derate linearly 4.29 mW/°C for TA > +25°C. 6.90 mW/°C for U4.
(2) Derate linearly 57.2 mW/°C for TC > +25°C. 86 mW/°C for U4.
(3) Derate linearly 12.5 mW/°C for TSP > +25°C.
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil . Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.dla.mil .
AMSC N/A
FSC 5961
