MIL-PRF-19500-485 Semiconductor Device, Transistor, Pnp, Silicon, Low-Power Types: 2N5415, 2N5415S, 2N5415Ua, 2N5415U4, 2N5416, 2N5416S, 2N5416Ua, And 2N5416U4, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhcb, Janhcd, Jankcb, Jankcd, Jankcbm, Jankcbd, Jankcbp, Jankcbl, Jankcbr, Jankcbf, Jankcbg, And JankcbhThis specification covers the performance requirements for PNP, silicon, switching transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type. Provisions for radiation hardness assurance \(RHA\) to eight radiation levels is provided for JANTXV, JANS, JANHC, and JANKC product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. .
MIL-PRF-19500/485N
TABLE III. Group E inspection (all quality levels) - for qualification or requalification only.
Inspection
MIL-STD-750
Qualification
Method
Conditions
45 devices
Subgroup 1
c=0
Temperature cycling
1051
Test condition C, 500 cycles.
(air to air)
Hermetic seal
1071
Fine leak
Gross leak
Electrical
See table I, subgroup 2 herein.
measurements
Subgroup 2
45 devices
c=0
Intermittent life
1037
VCB = 10 V dc, 6,000 cycles. Adjust device current, or power, to
achieve a minimum ĆTJ of +100°C.
Electrical
See table I, subgroup 2 herein.
measurements
Subgroup 4
15 devices,
c=0
Thermal resistance
3131
RθJSP can be calculated but shall be measured once in the same
package with a similar die size to confirm calculations (may apply to
multiple specification sheets).
Thermal impedance
See MIL-PRF-19500, table E-IX, group E, subgroup 4.
curves
Subgroup 5
15 devices
c=0
Barometric pressure
1001
Normal mounting; pressure = 8 mm Hg for 60 seconds minimum.
reduced (altitude
operation).
Subgroup 6
11 devices
ESD
1020
45 devices
Subgroup 8
c=0
Condition A for devices ≥ 400 V dc.
Reverse stability
1033
Condition B for devices < 400 V dc.
18
