MIL-PRF-19500/505E

* TABLE II. Group E inspection (all quality levels) - for qualification or re-qualification only.

Inspection

MIL-STD-750

Qualification and large lot

quality conformance

inspection

Method

Conditions

45 devices

Subgroup 1

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

Hermetic seal

1071

Fine leak

Test conditions G or H.

Gross leak

Test conditions C or D.

End-point electrical

See table I, subgroup 2 herein.

measurements

Subgroup 2

45 devices

c=0

Intermittent operation life: VCB  10 V dc,

Intermittent life

1037

6,000 cycles.

See table I, subgroup 2 herein.

End-point electrical

measurements

Subgroup 4

Thermal impedance curves

See table E-IX of MIL-PRF-19500, group E,

subgroup 4.

Subgroup 5

Not applicable

Subgroup 6

3 devices

Electrostatic discharge

1020

(ESD)

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
