MIL-PRF-19500/509D
* TABLE I. Group A inspection - Continued.
MIL-STD-750
Limits
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5
3051
Safe operating area
TC = +25°C; t = 1 s;
(dc operation)
1 cycle (see figure 3)
Test 1
(Both device types)
IC = 25 A dc; VCE = 8 V dc
Test 2
(Both device types)
IC = 14 A dc; VCE = 14 V dc
Test 3
IC = 100 mA dc; VCE = 100 V dc
2N6338
IC = 66 mA dc; VCE = 150 V dc
2N6341
3053
Load condition C; (unclamped
Safe operating area
inductive load) see figure 5
(switching)
TC = +25°C; duty cycle ≤ 10
percent; Rs = 0.1Ω;
tr = tf ≤ 500 ns
Test 1
tp ≈ 5 ms (vary to obtain IC);
RBB1 = 10 Ω; VBB1 = 20 V dc;
RBB2 = ∞; VBB2 = 0;
VCC = 50 V dc; IC = 20 A dc
L = 3 µH
Test 2
tp ≈ 5 ms (vary to obtain IC);
RBB1 = 100 Ω; VBB1 = 10 V dc;
RBB2 = ∞; VBB2 = 0;
VCC = 50 V dc; IC = 200 mA dc
L = 10 mH
See footnotes at end of table.
10
