MIL-PRF-19500/509D
* TABLE I. Group A inspection - Continued.
MIL-STD-750
Limits
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5 - Continued
Clamped inductive load;
3053
Safe operating area
(switching)
TA = +25°C; duty cycle ≤ 5
percent; tp ≈ 1.5 ms (vary
to obtain IC); VCC ≈ 50 V dc;
IC ≈ 25 A dc; (see figure 6)
2N6338
Clamped voltage = 100 V dc
2N6341
Clamped voltage = 150 V dc
Electrical measurements
See table I, subgroup 2 herein.
1/ For sampling plan see MIL-PRF-19500.
2/ The sample units subjected to the high-temperature operation test shall be permitted to return to and be
stabilized at room ambient temperature prior to their being subjected to the low-temperature operation test.
11
