MIL-PRF-19500/509D
Maximum Thermal Impedance
2N6338 and 2N6341
10
1
0.1
0.01
0.001
0.000001
0.00001
0.0001
0.001
0.01
0.1
1
10
Time (s)
Tc = 25°C. Thermal resistance = 0.875°C/W.
* FIGURE 4. Thermal impedance graph (RθJC) for 2N6338 and 2N6341 (similar to TO-204AA).
15
