MIL-PRF-19500-516 Semiconductor Device, Diode Silicon, Bipolar Transient Voltage Suppressor, Types 1N6102 Through 1N6137, 1N6102A Through 1N6137A, 1N6138 Through 1N6173, 1N6138A Through 1N6173A, 1N6102Us Through 1N6137Us, 1N6102Aus Through 1N6137Aus, 1N6138Us Through 1N6173Us, 1N6138Aus Through 1N6173Aus, 1N6102Urs Through 1N6137Urs, 1N6102Aurs Through 1N6137Aurs, 1N6138Urs Through 1N617...This specification covers the performance requirements for bipolar 500 watt and 1,500 watt peak pulse power transient voltage suppressor diodes. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for die. The suffix "A" denotes a five percent voltage tolerance.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/516F
4.3 Screening (JANS, JANTX, and JANTXV levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Screen
Measurement
(see table E-IV of
JANS level
JANTX and JANTXV levels
MIL-PRF-19500)
5
Not applicable
Not applicable
9, 10, 11
Not applicable
Not applicable
12
See 4.5.1
See 4.5.1
13
Interim electrical, delta, and group A,
Interim electrical, delta, and group A, subgroup
subgroup 2, electrical parameters not
2, electrical parameters not applicable for this
applicable for this screen (performed in
screen (performed in screen 12).
screen 12).
4.3.1 Screening (JANHC and JANKC die). Screening of JANHC and JANKC die shall be in accordance with
MIL-PRF-19500. As a minimum, die shall be 100-percent probed in accordance with table I, subgroup 2 herein.
4.4 Conformance inspection. Conformance inspection shall be in accordance with MIL-PRF-19500, and as
specified herein. A separate quality conformance inspection shall be required for the 500-watt and 1,500-watt peak
pulse power devices, respectively.
4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with MIL-PRF-19500 and table I
herein.
4.4.2 Group B inspection. Group B inspection shall be conducted in accordance with the conditions specified for
subgroup testing in table E-VIa (JANS) and table E-VIb (JAN, JANTX, and JANTXV) of MIL-PRF-19500, and as
follows. Electrical measurements (end-points) and delta requirements shall be performed twice (once in each
direction), in accordance with table I, subgroup 2 herein.
* 4.4.2.1 Group B inspection, table E-VIa (JANS) of MIL-PRF-19500.
Subgroup
Method
Condition
B4
Not applicable.
TA = +100°C minimum (see 4.5.2 and 4.5.3).
B5
1027
4.4.2.2 Group B inspection, table E-VIb (JAN, JANTX, and JANTXV) of MIL-PRF-19500.
Subgroup
Method
Condition
B3
1027
See 4.5.1.
B5
Not applicable.
Delta limits: ĆID1 ≤ 100 percent of initial reading or 20 percent of column 5 of table II,
B6
whichever is greater; ĆV(BR) ≤ 5 percent of initial value.
