MILPRF19500/523D
TABLE I. Group A inspection Continued.
Symbol
Limit
Inspection 1/
Unit
Method
Conditions
Min
Max
Subgroup 5
TC = +25°C; t = 1.0 s, 1 cycle
Safe operating area
3051
(continuous dc)
See figure 3
Test 1
VCE = 10 V dc; IC = 10 A dc
(All device types)
Test 2
VCE = 30 V dc; IC = 3.33 A dc
(All device types)
Test 3
VCE = 40 V dc, IC = 1.5 A dc
2N6383
VCE = 60 V dc, IC = 0.4 A dc
2N6384
VCE = 80 V dc, IC = 0.16 A dc
2N6385
Electrical measurements
See of table I, subgroup 2 herein
Safe operating area
3053
Load condition C (unclamped
(switching)
inductive load), see figure 4.
TC = 25°C, duty cycle ≤ 10 percent
RS = 0.1Ω
Test 1
tp approximately 1 ms (vary to
obtain IC);
RBB1 = 1 kΩ; VBB1 = 10 V dc;
RBB2 = ∞; VBB2 = 0 V;
VCC = 30 V dc; IC = 10 A dc;
RL ≤ 0.5 Ω; L = 1 mH at 10 A dc
Electrical measurements
See subgroup 2 of this table
Test 2
tp approximately 1 ms (vary to
obtain IC);
RBB1 = 10 KΩ; VBB1 = 10 V dc;
RBB2 = ∞; VBB2 = 0 V;
VCC = 30 V dc; IC = 0.2 A dc;
L = 100 mH at 0.2 A dc; RL ≤ 0.5 Ω
Electrical measurements
See of table I, subgroup 2 herein
See footnotes at end of table.
