MIL-PRF-19500/540F
11 April 2014
SUPERSEDING
MIL-PRF-19500/540E
10 September 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DARLINGTON TRANSISTOR, PNP SILICON, POWER,
TYPES 2N6298 AND 2N6299, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, Darlington, silicon, power
transistors. Three levels of product assurance is provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (similar to TO-66).
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
*
RθJC
Type
PT (1)
VCBO
VCEO
VEBO
IC
IB
TJ and TSTG
TC = 25°C
TC = +100°C
°C/W
°C
W
W
V dc
V dc
V dc
A dc
mA dc
2N6298
64
32
-60
-60
-5
-8
-120
2.33
-65 to +175
2N6299
64
32
-80
-80
-5
-8
-120
2.33
-65 to +175
(1) Derate linearly at 0.428 W/°C above TC > 25°C.
1.4 Primary electrical characteristics. Unless otherwise specified, TC = +25°C.
*
hfe
Cobo
hFE2 (1)
hFE3 (1)
Pulse
VBE(sat)
VCE(sat)2
hfe
VCE = -3 V 100 kHz ≤ f
Limits
response
≤ 1 MHz
(1)
(1)
VCE = -3 V dc
dc
VCE = -3 V dc VCE = -3 V dc IC = -3 A dc VCB = -10 V dc
IC = -8 A dc
IC = -8 A dc
IC = -3 A dc
ton toff IB = -80 mA dc IB = -80 mA dc
IC = -4 A dc IC = -8 A dc f = 1 MHz
IE = 0
f = 1 kHz
µs
µs
pF
V dc
V dc
Min
750
100
25
300
Max
18,000
350
200
-4.0
-3.0
2.0
8.0
(1) Pulsed (see 4.5.1).
