MIL-PRF-19500/540F
* TABLE I. Group A inspection - Continued.
Inspection 1/
Symbol
Limits
Unit
Min
Max
Method
Conditions
Subgroup 5
TC. = 25°C +10°C, t = 1 s;
3051
Safe operating area (dc)
1 cycle; see figure 4;
VCE = -8 V dc; IC = -8 A dc
Test 1
VCE = -20 V dc; IC = -2.0 A dc
Test 2
Test 3
IC = -100 mA dc
2N6298
VCE = -60 V dc
2N6299
VCE = -80 V dc
Safe operating area
3053
Load condition B,
(switching)
(clamped inductive load);
TA = +25°C; tr + tf ≤1.0 µs
duty cycle ≤ 10 percent,
tp = 1 ms; (vary to obtain IC);
RS = 0.1 ohms; RBB1 = 80 ohms;
VBB1 = -16 V dc;
RBB2 = 100 ohms;
VBB2 = -1.5 V dc; VCC = -50 V dc;
IC = -8 A dc; RL ≤ 2 ohms;
L = 1 mH; clamp voltage
2N6298
-60 V dc
2N6299
-80 V dc
Safe operation area
3053
Load condition C;
(switching)
(unclamped inductive load)
duty cycle ≤ 10 percent
RS = 0.1 ohms
Test 1
tp = 1 ms; (vary to obtain IC);
RBB1 = 80 ohms;
VBB1 ≥ -12 V dc; RBB2 = ∞;
VCC ≥ -30 V dc; IC = -8 A dc;
RL ≤ 0.5 ohms;
L = 1 mH at 8 A dc
See footnotes at end of table.
8
