MIL-PRF-19500/540F
* TABLE I. Group A inspection - Continued.
Inspection 1/
Symbol
Limits
Unit
Min
Max
Method
Conditions
Subgroup 5 - Continued
Test 2
tp = 1 ms; (vary to obtain IC);
RBB1 = 80 ohms;
VBB1 ≥ -12 V dc; RBB2 = ∞ ;
VBB2 = 0 V dc; VCC = -30 V dc;
IC = -0.2 A dc; RL ≤ 0.5 ohms;
L = 100 mH; at -0.2 A dc
End point electrical
measurements:
Collector to emitter
3041
ICEX1
Bias condition A;
cutoff current
VBE = -1.5 V dc
2N6298
-0.5
mA dc
VCE = -60 V dc
2N6299
-0.5
mA dc
VCE = -80 V dc
Forward-current
3076
750
18,000
VCE = -3 V dc; IC = -4 A dc;
hFE2
transfer ratio
pulsed (see 4.5.1)
1/ For sampling plan, see MIL-PRF-19500.
2/ This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
9
