MIL-PRF-19500-542 Semiconductor Device, Transistor, Field Effect, N-Channel, Silicon, Types 2N6756, 2N6758, 2N6760, 2N6762, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for N-channel, enhancement-mode, MOSFET, power transistors. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500 and two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

MIL-PRF-19500/542J

6.5 Replacement data. JANTX devices shall be a direct replacement for JAN devices (example: JANTX2N6756

for JAN2N6756).

6.6 Suppliers of JANHC and JANKC die. The qualified die suppliers with the applicable letter version (example

JANHCA2N6756) will be identified on the QML.

JANC ordering information

Manufacturers

59993

43611

2N6756

JANHCA6756

JANHCC2N6756

JANKCA6756

JANKCC2N6756

2N6758

JANHCA6758

JANHCC2N6758

JANKCA6758

JANKCC2N6758

2N6760

JANHCA6760

JANKCA6760

2N6762

JANHCA6762

JANKCA6762

6.7 Changes from previous issue. The margins of this specification are marked with asterisks to indicate where

changes from the previous issue were made. This was done as a convenience only and the Government assumes

no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the

requirements of this document based on the entire content irrespective of the marginal notations and relationship to

the last previous issue.

Custodians:

Preparing activity:

Army - CR

DLA - CC

Navy - EC

Air Force - 85

(Project 5961-2011-053)

NASA - NA

DLA - CC

Review activities:

Navy - AS

Air Force - 19, 70

NOTE: The activities listed above were interested in this document as of the date of this document. Since

organizations and responsibilities can change, you should verify the currency of the information above using the
