INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/542J
shall be completed by 22 December 2011.
22 September 2011
SUPERSEDING
MIL-PRF-19500/542H
26 April 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, FIELD EFFECT, N-CHANNEL,
SILICON, TYPES 2N6756, 2N6758, 2N6760, 2N6762,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for N-channel, enhancement-mode, MOSFET,
power transistors. Four levels of product assurance are provided for each encapsulated device type as specified in
MIL-PRF-19500 and two levels of product assurance are provided for each unencapsulated device type.
1.2 Physical dimensions. See figure 1 (TO-204AA; formerly TO-3), figure 2, and 3 for JANHC and JANKC die
dimensions. See 6.6 for unencapsulated device types.
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT (1)
PT
VDS
VDG
VGS
ID1 (2) (3)
ID2 (2)
Type
TC = +25°C
TC = +100°C
TC =
TC =
+25°C
+25°C
(free air)
W
W
V dc
V dc
V dc
A dc
A dc
± 20
2N6756
75
4
100
100
14.0
9.0
± 20
2N6758
75
4
200
200
9.0
6.0
± 20
2N6760
75
4
400
400
5.5
3.5
± 20
2N6762
75
4
500
500
4.5
3.0
IS
IDM
TJ and TSTG
VISO
Max rDS(on) (1)
RθJC
Type
VGS = 10 V dc, ID = ID2
100,000
feet
max
TJ = +25°C
TJ = +150°C
(4)
altitude
°C
°C/W
A dc
A (pk)
ohms
ohms
2N6756
14.0
56
0.18
0.36
-55 to +150
1.67
2N6758
9.0
36
0.4
0.84
-55 to +150
1.67
2N6760
5.5
22
400
1.0
2.5
-55 to +150
1.67
2N6762
4.5
18
500
1.5
3.75
-55 to +150
1.67
See notes on next page.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
