MIL-PRF-19500-555 Semiconductor Device, Field Effect Transistor, N-Channel, Silicon, Types 2N6788, 2N6788U, 2N6790, 2N6790U, 2N6792, 2N6792U, 2N6794, And 2N6794U, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for an N-channel, enhancement-mode, MOSFET, power transistor. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

MIL-PRF-19500/555L

Symbol

Dimensions

Inches

Millimeters

Min

Max

Min

Max

.345

.360

8.77

9.14

.280

.295

7.12

7.49

.095

.115

2.42

2.92

.040

.055

1.02

1.39

LL1

.055

.065

1.40

1.65

LL2

.050 BSC

1.27 BSC

.025 BSC

0.635 BSC

LS1

.008 BSC

0.203 BSC

LS2

.020

.030

0.51

0.76

.105 REF

2.67 REF

.120 REF

3.05 REF

.045

.055

1.15

1.39

.070

.080

1.78

2.03

.120

.130

3.05

3.30

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Dimensions and tolerancing shall be in accordance with ASME Y14.5M.

FIGURE 2. Physical dimensions for LCC (2N6788U, 2N6790U, 2N6792U, and 2N6794U) - Continued.
