MIL-PRF-19500/558J
completed by 28 June 2013.
29 March 2013
SUPERSEDING
MIL-PRF-19500/558H
23 May 2011
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, UNITIZED, PNP, SILICON, SWITCHING,
FOUR TRANSISTOR ARRAY, TYPES 2N6987, 2N6987U, AND 2N6988,
JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL,
JANSR, JANSF, JANSG, AND JANSH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, switching transistors, four
independent chip array. Four levels of product assurance are provided for each device type as specified in
MIL-PRF-19500. Radiation hardness assurance (RHA) level designators "M", "D", "P", "L", "R", "F", "G", and "H" are
appended to the device prefix to identify devices which have passed RHA requirements.
1.2 Physical dimensions. See figures 1, 2, 3, and 4 (14-pin dual-in-line, 14-pin flat-pack, and 20-pin leadless chip
carrier).
1.3 Maximum ratings, unless otherwise specified TA = +25°C. (1)
PT
PT
VCBO
VEBO
VCEO
IC (3)
TJ and
RθJA
RθJA(AM)
TA = +25°C
TA(AM) = +25°C
(5)
(5)
(5)
TSTG
(3)
(3) (4)
(2)
(2)
°C/W
°C/W
°C
W
W
V dc
V dc
V dc
mA dc
2N6987
1.5
N/A
85
N/A
60
5
60
600
-65
2N6987U
1.0
N/A
160
N/A
60
5
60
600
to
2N6988
1.0
1.0
175
23
60
5
60
600
+200
Maximum voltage between transistors shall be ≥ 500 V dc.
(1)
(2)
For derating see figures 5, 6, 7, and 8.
(3)
For thermal impedance graphs, see figures 9, 10, 11, and 12.
(4)
Thermally conductive adhesive mount to infinite heat sink.
(5)
Ratings apply to each transistor in the array.
